Description

You can adjust the low-pass filter and subsonic filter to get the best possible sound from your sub and enclosure. In the unlikely event you want to bump up the bass a little, you also have access to a selectable bass boost.

-mono subwoofer amplifier
-300 watts RMS x 1 at 4 ohms (500 watts RMS x 1 at 2 ohms)
-variable low-pass filter (40-220 Hz, 12 dB/octave)
-selectable bass boost (0, 6, 12 dB at 50 Hz)
-variable subsonic filter (10-50 Hz, 12 dB/octave)
-Class-D amplifier design
-frequency response: 10-220 Hz
-preamp inputs
-4-gauge power and ground leads and a 60-amp fuse recommended — wiring and hardware not included with amplifier
-no onboard fuses — when installing multiple amps in a system, an additional 60-amp in-line fuse between the distribution block and the amplifier is recommended
-9-1/2″W x 2-3/16″H x 5-9/16″D
